Function to insert a new roof in the activated floor/room.



After clicking DeckeNEu the calculation of opaque components opens:





Choose a component and confirm with "OK".

RM_HL_1





The new roof is displayed.

By clicking on the orientation and the indination, those values can be edited.

RM_new roof
