These function opens the component parts drawing function.
Access to the command over: |
AutoCAD/BricsCAD |
|
|---|---|
Command line: _KANAL2_SPR
Assistant: |
Drawing procedure for pipes:
1. |
Activate the function |
2. |
Pick starting point
|
3. |
Pick second point
|
4. |
These points will be shown as pipes in preview first.
|
5. |
The function for drawing Duct parts opens. You can here edit the Fittings as needed.
|
If Trade Definition is activated, the automatic layer manager will be activated only at non AX3000 layers (e.g. layer 0).
