This function opens the drawing function for special fittings.
Click on 2 pipework points in plan. These points will first be shown as pipes in preview. The Special fitting shown at the end of pipework can be changed with corresponding buttons.
If Trade definition is activated, the automatic layer manegement will be activated for layers not defined by AX3000 (e.g. layer 0) after the first pipe point. The second pipe point can be selected afterwards.
Access to the command over: |
AutoCAD/BricsCAD |
|
|---|---|
Command line: _KANAL1_H
Assistant: |
Drawing procedure for pipes:
1. |
Activate the function. |
2. |
Pick starting point
|
3. |
Pick second point
|
4. |
These points will be shown as pipes in preview first.
|
5. |
The function for drawing Pipe parts opens. You can here edit the Fittings as needed.
|
